Description
HDMI seamlessmatrix switcher, the biggest feature of the matrix is that natural black field (normal 2_10s)will not appear asin the traditional matrix in all output switching processes, achieve thetrue sense of the seamlessswitching matrix. Input and output are modular design, meet the maximum configuration, more conducive to maintenance. It supports a varietyof signals input, andall input and output can beswitched seamlesslyand arbitrarily. The matrix usestouch control, RS232/LAN and other ways to facilitateusers to connect with othercontrol systems. The device works continuously in 7*24 hours, therebyensure the product's stability. There are 8*8/ 16*16/ 32*32/ 64*64 four types bynow, OEM of other typesare welcome.
Click here for product PDF file
Click here for product full manual
Click here for product tutorial (PC control)
Additional information
| Weight | 8.50 kg |
|---|---|
| Dimensions | 59.00 × 49.00 × 15.00 cm |
| Warranty | 1 Year Warranty |
| What's in the box | 1* HDMI Seamless Matrix |
