Features
• 16 or 24 Gigabit Ethernet ports for fast network speeds and backwards compatibility
• Durable metal housing
• Fanless design for silent operation Performance
• IEEE 802.3x Flow Control
• Auto MDI/MDI-X crossover for all ports
• Half/full-duplex for Ethernet/Fast Ethernet
• Supports up to 10,000 bytes jumbo frames
• Innovative D-Link Green Ethernet technology
• Link status detection
• 802.3az Energy-Efficient Ethernet (EEE)
• RoHS-compliant
• Plug-and-play installation with no additional configuration required
• Energy-Efficient Ethernet (EEE), Flow Control, Port Isolation, and Storm Control
| Technical Specifications | |
| General | DGS-1016D |
| Number of Ports | 16 10/100/1000 Mbps ports |
| Standards | • IEEE 802.3 10BASE-T
• IEEE 802.3u 100BASE-TX • IEEE 802.1p Quality of Service (QoS) • IEEE 802.3x Flow Control supported for full-duplex • Auto-negotiation • IEEE 802.3az Energy-Efficient Ethernet (EEE) |
| Data Transfer Rates | • Ethernet: 10 Mbps/20 Mbps (half-duplex/full-duplex)
• Fast Ethernet: 100 Mbps/200 Mbps (half-duplex/full-duplex) • Gigabit Ethernet: 2000 Mbps (full-duplex) |
| Network Cables | • Ethernet: 2-pair UTP Cat.3/4/5/5e, Unshielded Twisted Pair (UTP) Cable
• Fast Ethernet: 2-pair UTP Cat.5/5e, Unshielded Twisted Pair (UTP) Cable • Gigabit Ethernet: 4-pair UTP Cat.5/5e, Unshielded Twisted Pair (UTP) Cable |
| Functionality | |
| D-Link Green Features | Power saving by link status and cable length |
| Security | Storm Control |
| QoS (Quality of Service) | • 802.1p priority
• 8 queues |
| Cable Diagnostics | Indicated through port LEDs |
| Switching Features | |
| Protocol | CSMA/CD |
| Switching Capacity | 32 Gbps |
| Max. Forwarding Rate | 23.81 mpps |
| Packet Buffer RAM | 512 KBytes per device |
| Filtering Address Table | 8K MAC addresses per device |
| Packet Filtering/Forwarding Rate | • Ethernet: 14,880 pps per port
• Fast Ethernet: 148,800 pps per port • Gigabit Ethernet: 1,488,000 pps per port |
| MAC Address Learning | Self-learning, auto-aging |
| Forwarding Mode | Store-and-forward |
