FEATURES

• Transmission Range: Up to 990ft (300 meters)

• Accepts Digital Coax or Optical Toslink

• Supports Digital 5.1 (DTS, Dolby Digital, etc.)

• High performance, zero signal loss

• Data Transmission Rate: 12.8 Mb/s

• S/PDIF (Digital Coax): 96 kHz performance

SPECIFICATIONS

Operating Temperature Range	-5 to +35℃(+23 to +95℉)
Operating Humidity Range	5 to 90%RH (No Condensation)
Data transfer speed	12.8 Mb/s
Connectors Transmitter	1xCat5e/6 out    1xPower DC    2xAudio in(for Optical and Coaxial)
Connectors Receiver	1xCat5e/6 in    2xAudio out(for Optical and Coaxial)
Audio format	Dolby 5.1, DTS Digital etc
Power consumption	1watts(Maximum)
Dimension (L×W×H)	60.5×46.5x20mm
Net Weight	150g(Pair)

PANEL DESCRIPTIONS



DC5V power

Cat5E/6 output port

Coaxial input port

Optical input port







• Cat5E/6 input port
• Coaxial output port
• Optical output port



CONNECTING AND OPERATING





• Connect the HDMI input source (such as HD-DVD/PS3/STB etc) into transmitter over HDMI cable.

• Connect the output of transmitter and input of receiver over CAT5E or CAT6 cable.

• Connect the HDMI output (such as HD-LCD/HD-DLP) into the receiver over HDMI cable.

• Connect power adapter in to the transmitter. NOTE: Insert/Extract cables gently.







Click here for product PDF file

Click here for product manual



Weight	0.5 kg
Dimensions	20.5 × 15 × 5.5 cm
Warranty	3 Months Warranty
What's in the box	2* Audio Extender Over Lan Cable 1* User Manual 1* 5V/1A Power Adapter
