Description
Introduction:
This product is a high performance 2 by 1 Multi-Viewer. It supports two High definition input source display on one screen. As a Multi-Viewer, it can display on one screen in 4 modes.
Features:
- Compliant with HDMI 1.3a, HDCP 1.2
- Supports multiplexed HDMI 2-input and 1-output and 4 display modes
- Supports up to 1080p High Definition resolution
- Support scaler up, scaler down function
- Support multi output resolution
- Support digital audio format LPCM/AC3/DTS
Specification:
| Video Bandwidth | 225MHz [6.75Gbps] |
| Input Ports | 2xHDMI (Female Type) |
| Output Ports | 1xHDMI (Female Type) |
| Audio output | PCM2, 5.1, 7.1CH, Dolby 5.1, DTS5.1 |
| Input Resolution | 480i60Hz, 480p60Hz, 576i50Hz, 576p50Hz, 720p50/60Hz, 1080i50/60Hz, 1080p24/30/50/60Hz, 800×600@60, 1024×768@60, 1280×720@60, 1920×1080@60 |
| Output Resolution | 1080p, 720p, 1080i, 1024×768, 1360×768 |
| ESD Protection | Human Body model: ±8kV (air-gap discharge)
±4kV (contact discharge) |
| Power Supply | 5V/1A DC (US/EU standards, CE/FCC/UL certified) |
| Dimensions | 70mm(W)x140mm(D)x25mm(H) |
| Weight | 300g |
| Chassis Material | Metal |
| Operating Temperature | 0°C~40°C |
| Storage Temperature | -20°C~60°C |
| Relative Humidity | 20~90% RH (non-condensing) |
| Power Consumption | 10W |
Mode1
Mode2
Additional information
| Weight | 0.6 kg |
|---|---|
| Dimensions | 21 × 5.5 × 14.5 cm |
| Warranty | 3 Months Warranty |
| What's in the box | 1* HDMI 2 Port Multi Viewer |
